AEM water electrolysis hydrogen production equipment
  • AEM electrolytic cell
广泛应用于电子、电力、核电、航空、军工等领域。 l 运行压力最高可达到5.0MPa。 l 根据客户要求可以设计成集装箱式、撬装式或柜式结构。 l 自动化控制，可实现无人值守。 l 通过互联网可实现超远程监控。


AEM (Anion Exchange Membrane) electrolysis cell is an efficient and economical water electrolysis hydrogen production equipment, which combines the low cost of alkaline electrolysis cell with the high efficiency advantage of proton exchange membrane (PEM) electrolysis cell. Its core is a highly conductive anion exchange membrane that supports wide load dynamic response and adapts to fluctuating renewable energy inputs such as wind power and photovoltaics. The maximum current density of AEM electrolytic cell reaches 2 A/cm ² @ 2V, and the energy consumption under rated conditions (current density of 1A/cm ²) is less than 4.25 kWh/Nm ³ H ₂, and there is no demand for precious metal catalysts. Widely used in fields such as renewable energy storage, chemical metallurgy, hydrogen fuel cell vehicles, etc., to help achieve carbon neutrality goals.

1. AEM membrane: self-made

2. Cathode: Non precious metal

3. Anode: Non precious metal

4. Rated hydrogen production capacity: 10Nm ³

5. Power regulation range: 20~120%

6. Rated current density: 1A/cm ² @ 1.8V

7. Operating pressure: 1.6 MPa

8. Operating temperature meets: 60 ° C ± 2 ℃

9. Hot start time<10s, cold start time<10min

10. DC power consumption 3.6~4.5 kWh/Nm3H

11. Adopting lightweight design - plastic pole frame
